Teltonika TRB140 LTE Router: No WiFi, 4G, SIM, Enthernet port, Micro USB | LTE Router | TRB140 | No Wi-Fi | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | Mesh Support No | MU-MiMO No | 2G/3G/4G | Antenna type 1 x SMA for LTE | 1 x Virtual network interface via micro USB | 24 month(s)
Gross depth (mm) |
175 |
Gross height (mm) |
150 |
Gross weight |
0.43 |
Gross width (mm) |
70.00 |
Net weight |
0.307 |
Packing quantity |
10 |
Paper/Pasteboard |
123 |
Tare weight (kg) |
0.123 |
Volume (m3) |
0.0018375 |
Embeeded battery |
No |
WEEE tax |
Yes |
WEEE tax |
CL109:6:2017-04-01 |
Ethernet LAN-i andmeedastuskiirused |
10/100/1000 |
USB liideste arv |
1 x Virtual network interface via micro USB |
Producer product name |
TRB140 |
Producer product family |
LTE Router |
Ethernet LAN (RJ-45) pordid |
1 |
Wi-Fi sagedus |
No Wi-Fi |
Tarkvara tüüp |
RutOS (OpenWrt based Linux OS) |
Mesh Support |
No |
Mobile Broadband |
2G/3G/4G |
MU-MiMO |
No |
Antenni tüüp |
1 x SMA for LTE |
Protsessori mudel |
ARM Cortex-A7 1.2 GHz CPU |
Warranty |
24 |
Sisemälu |
128 MB (50 MB available for userspace) |
Korpuse materjal |
Aluminum |
Suhteline õhuniiskus kasutamisel (H-H) |
10 % to 90 % non-condensing |
Mõõdud (l x s x k) |
74,5x64,4xx25 |
Kasutamistemperatuur (T-T) |
-40 °C to 75 °C |
PoE in |
Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards |
Sisendpinge |
9 – 30 VDC (4 pin industrial socket), reverse polarity protection, surge protection >33 VDC 10us max |
Toetatud protokollid |
HTTP(S), MQTT, Azure MQTT, Kinesis |
Tulemüür |
Pre-configured firewall rules can be enabled via the WebUI, unlimited firewall configuration via CLI; NAT; NAT-T |
Toetatud võrguprotokollid |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL) |
Gross depth master carton |
375 |
Gross width master carton |
370 |
Gross height master carton |
170 |
Net weight master carton |
4.3 |
Tare weight master carton |
0.401 |
Producer |
Teltonika |
Palette Qty |
730 |
