PoE hub controlled 100Mbps 24 ports+2G uplink + 2SFP, Hi-PoE

559 €

Monthly payment starting from 19,05 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

Cloud Managed Switch is a layer 2 advertising switch with long distance PoE function. It can power devices up to 250 meters away. The red PoE port delivers up to 90W. The Switch can be controlled using the DoLynk Care app, which provides access to a network topology diagram feature that can be used to quickly troubleshoot problems. The DoLynk Care app is built on top of the DoLynk Care Cloud Server. The switch is suitable for use in a variety of applications such as homes, factories and offices. Model: S4101-24ET2GF-360-C.
Add to cart

Delivery in 7-10 working days

Free delivery

14 14 days return policy when purchasing online

26-port managed hub with 24-port PoE, 250m, max 360W, model S4101-24ET2GF-360-C.

Cloud Managed Switch is a layer 2 advertising switch, having long range PoE function. It can power devices up to 250 meters away. The red PoE port delivers up to 90W. The Switch can be controlled using the DoLynk Care app, which provides access to a network topology diagram feature that can be used to quickly troubleshoot problems. The DoLynk Care app is built on top of the DoLynk Care Cloud Server. The switch is suitable for use in a variety of applications such as homes, factories and offices. Model: S4101-24ET2GF-360-C.

Features:

  • Supports LLDP protocol and automatically generates network topology for fast to identify problems.< br /> Cloud management: you can control and maintain the switch through the mobile terminal app, greatly reducing the operation and maintenance costs.
  • The transmission distance of the PoE port can be up to 250m, which meets the requirement of wired transmission (bandwidth reduced up to 10Mbps).
  • Supports visualized control and remote maintenance.
  • Supports automatic generation of network topology.
  • 250m remote power supply.
  • 8-pin PoE provides better compatibility and reduces wire loss.
  • PoE monitoring software monitors the status of terminals in real time.
  • Supports power management policies.
  • Red port 90 W: Red ports support IEEE802.3af, IEEE802.3at, IEEE802.3bt and Hi-PoE standards with a maximum output power consumption of 90W per port. Suitable for powering high-power devices.
  • PoE Watchdog: Allows the switch to automatically detect port status and restart failed ports to restore communication in the event of an IPC communication exception. It enables intelligent operation and maintenance management in the true sense and effectively reduces manual maintenance costs.


Technical specification:

  • Power adapter included: Yes.
  • PoE: Yes.
  • Ethernet port: 24.
  • Ethernet port speed 10/100 Mbps.
  • Optical port Uplink speed: 1 Gbps.
  • Description of function slots: 1-24 port: 24 × 10M / 100M Base-T (PoE); Port 25-26: 2 × 10M / 100M / 1000M Base-T (uplink transmitter) (combined); Port 25-26: 2 × 1000M SFP (Highland) (combined).
  • Power: 100-240VAC, 50/60Hz, 2A.
  • Operating Temperature: - 10°C to +55°C.
  • Operating humidity: 5%-95% (RH), non-condensing.
  • Storage temperature -40°C to +70°C.
  • Storage humidity 5%-95% (RH), non-condensing.
  • Idle power consumption: <5W, Full: 360W.
  • MTBF: 337 713 h.
  • Switching capacity: 8.8 Gbps.
  • Packet forwarding speed: 6.54 Mps.
  • Packet buffer size: 4 Mbit.
  • MAC table size: 16K.
  • PoE protocol: IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt.
  • PoE Power: Port 1-2 <90W; Port 3-24 <30W; Total <360 W.
  • PoE Power Management: Yes.
  • PoE Pin Assignment: 1, 2, 4, 5 (V+), 3, 6, 7, 8 ( V–).
  • Long distance PoE transmission: Yes.
  • Static protection: Air discharge: 8 kV; Contact discharge: 6 kV.
  • Lighting Protection: General mode: 4 kV; Differential mode: 2 kV.
  • Weight: 3.50 kg.
  • Product dimensions: 440 mm × 300 mm × 44 mm.
  • Certificates CE; FCC.


Transmission performance:

  • Switching supply voltage 53V.
  • CAT5E/CAT6. Max. DC resistance < 10ohm/100m
  • Cable(m) Load(W) Bandwidth(Mbps)
  • IEEE802.3bt 90W:
  • 100m Cable; 71.3 W load; 100 Mbps bandwidth.
  • 150 m cable; 62W load; 10Mbps bandwidth.
  • 200m cable; 51W load; 10Mbps bandwidth.
  • 250m cable; 40W load; 10Mbps bandwidth.
  • Hi-PoE 60W:
  • 100m cable; 53W load; 100 Mbps bandwidth.
  • 150 m cable; 50W load; 10Mbps bandwidth.
  • 200m cable; 47W load; 10Mbps bandwidth.
  • 250m cable; 37W load; 10Mbps bandwidth.
  • IEEE802.3at 30W:
  • 100m cable; 25.5 W load; 100 Mbps bandwidth.
  • 150 m cable; 25.5W load; 10Mbps bandwidth.
  • 200m cable; 25.5W load; 10Mbps bandwidth.
  • 250m cable; 25.5W load; 10Mbps bandwidth.


Note: Actual transmission distance may vary due to power consumption of connected devices or cable type and condition.


Width 440 mm
Height 44 mm
Length 300 mm
Product Weight 1500 g
