TUF GAMING B550-PLUS AM4 DDR4 HDMI/DP M.2 AT

Addional discount of 2%
will be applied in shopping cart
(min. 12€ purchase)
166,99 €

Monthly payment starting from 5,69 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

Add to cart

Delivery in 7-10 working days

Free delivery

14 14 days return policy when purchasing online

TUF Gaming motherboards are designed to be easy to set up and configure just the way you want even for first-time builders. The TUF Gaming Alliance ecosystem makes selecting compatible parts easy, while Armoury Crate software offers full control of system settings via a single dashboard. TUF Gaming motherboards give you everything you need to build your dream gaming rig without adding complexity.

TUF Gaming B550-Plus provides a complete, high-performance gaming package with a long list of features to improve your experience, including ultrafast networking for smoother online gameplay, pristine audio with positional cues for FPS gaming, and onboard RGB lighting that syncs with attached accessories to help you create a personalized gaming atmosphere.

EXCLUSIVE 2.5 GIGABIT ETHERNET
2.5G on-board Ethernet kicks your LAN connection up a notch with an up to 2.5X bandwidth improvement. Using your existing LAN cable, you can take advantage this networking upgrade to experience smoother, lag-free gaming, immediately stream high-resolution videos and enjoy faster file transfers.


Model TUF Gaming B550-Plus
CPU socket Socket AM4
Processor family AMD Ryzen
Integrated CPU No
Chipset manufacturer AMD
Chipset type AMD B550
Memory type DDR4
Number of DDR4 slots 4
Memory bus frequency 4400 MHz
Memory bus frequency 4266 MHz
Memory bus frequency 4133 MHz
Memory bus frequency 2666 MHz
Memory bus frequency 2800 MHz
Memory bus frequency 3000 MHz
Memory bus frequency 3200 MHz
Memory bus frequency 3333 MHz
Memory bus frequency 3466 MHz
Memory bus frequency 3600 MHz
Memory bus frequency 3733 MHz
Memory bus frequency 3866 MHz
Memory bus frequency 4000 MHz
Memory bus frequency 2400 MHz
Memory bus frequency 4600 MHz
Memory bus frequency 2133 MHz
Max memory size 128
Expansion slots 1 x PCIe 3.0 x 1
Expansion slots 1 x PCIe 4.0 x 16
Expansion slots 1 x PCIe 3.0 x 16
Max. number of SATA devices 6
RAID Yes
Graphics 1 x DisplayPort 1.4 **1 x HDMI 2.1(4K@60HZ)
Sound card Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
Network interface 1 x 10/100/1000/2500 Mbit/s
Network interface Realtek RTL8125B 2.5Gb Ethernet TUF LANGuard
USB ports at back panel 8
USB ports on motherboard 6
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 2
FireWire (IEEE 1394) No
COM connector / port Yes
LPT connector / port No
External connectors 1 x USB 3.1 Type-C
External connectors 1 x USB BIOS Flashback button
External connectors 1 x Rear Speaker
External connectors 1 x Line In
External connectors 1 x Line Out
External connectors 1 x MIC
External connectors 1 x RJ-45
External connectors 1 x S/PDIF
External connectors 2 x USB 2.0
External connectors 4 x USB 3.0
External connectors 1 x USB 3.1
External connectors 1 x Side Speaker
External connectors 1 x DisplayPort
External connectors 1 x HDMI
Onboard connectors 1 x Serial port header
Onboard connectors 1 x TPM header
Onboard connectors 1 x System panel header
Onboard connectors 1 x 4pin CPU fan
Onboard connectors 1 x 4pin wentylator OPT CPU
Onboard connectors 1 x 8pin 12V power
Onboard connectors 1 x 24pin ATX zasilanie
Onboard connectors 3 x M.2
Onboard connectors 6 x SATA III 6Gb/s
Onboard connectors 2 x USB 2.0/1.1 header
Onboard connectors 1 x USB 3.0 header
Onboard connectors 1 x Front panel audio header
Onboard connectors 1 x Clear CMOS jumper
Onboard connectors 1 x Thermal sensor connector
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Form factor ATX
Dimensions 30.5 x 24.4 cm
Accessories included User manual 2 x SATA 6Gb / s cable DVD TUF sticker TUF certification card M.2 SSD screw pack
Supported operating systems Windows 10
Designation
Detailed data on disk/drive interfaces Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports 3rd Gen AMD Ryzen Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) AMD B550 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2

Dimensions and weights

Gross weight
1.6 kg
Package width
27.5 cm
Package height
7 cm
Package length
34 cm

Product codes

EAN
4718017749435
Manufacturer code
KBASUAA7B550A02
