Home page » Computers & IT»Computer components»CPUs»Intel Pentium Gold G7400 processor 3.7 GHz 6 MB Smart Cache Box

Intel Pentium Gold G7400 processor 3.7 GHz 6 MB Smart Cache Box

Main info

Product has been archived


Discrete graphics card model Not available
Number of execution units 16
CPU configuration (max) 1
On-board graphics card DirectX version 12.0
Maximum internal memory 128 GB
Maximum number of PCI Express lanes 20
Intel® Quick Sync Video Technology Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Virtualization Technology (VT-x) Yes
Processor cache type Smart Cache
On-board graphics card Yes
Stepping H0
Enhanced Intel SpeedStep Technology Yes
Intel® Secure Key Yes
Tjunction 100 °C
Intel VT-x with Extended Page Tables (EPT) Yes
Memory bandwidth (max) 76.8 GB/s
Intel® Turbo Boost Technology No
Processor threads 4
Processor package size 45 x 37.5 mm
Processor cores 2
Intel® Optane™ Memory Ready Yes
Processor model G7400
Processor operating modes 64-bit
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Discrete graphics card No
On-board graphics card model Intel UHD Graphics 710
Processor cache 6 MB
Processor family Intel® Pentium® Gold
Processor socket LGA 1700
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Processor codename Alder Lake
Memory channels Dual-channel
Intel® OS Guard Yes
Processor manufacturer Intel
Memory bandwidth supported by processor (max) 76.8 GB/s
Scalability 1S
Status Launched
Execute Disable Bit Yes
Processor ARK ID 219435
On-board graphics card ID 0x4693
Maximum number of DMI lanes 8
Use conditions PC/Client/Tablet
Direct Media Interface (DMI) Revision 4.0
OpenCL version 2.1
Multi-Format Codec Engines 1
Processor base power 46 W
Bus type DMI4
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Maximum internal memory supported by processor 128 GB
On-board graphics card base frequency 300 MHz
Intel® Standard Manageability (ISM) Yes
Intel® Control-flow Enforcement Technology (CET) Yes
On-board graphics card dynamic frequency (max) 1350 MHz
Idle States Yes
Number of displays supported (on-board graphics) 4
Intel® Thread Director No
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
Intel® Speed Shift Technology Yes
Harmonized System (HS) code 85423119
Intel® Boot Guard Yes
Intel® Volume Management Device (VMD) Yes
Processor base frequency 3.7 GHz
Market segment Desktop
Mode-based Execute Control (MBE) Yes
On-board graphics card OpenGL version 4.5
Intel Turbo Boost Max Technology 3.0 No
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
Intel 64 Yes
Performance cores 2
Performance-core base frequency 3.7 GHz
Export Control Classification Number (ECCN) 5A992CN3
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
Launch date Q1'22
Commodity Classification Automated Tracking System (CCATS) G167599
Warranty 36 (G)
PCI Express configurations 2x8+1x4
Thermal Monitoring Technologies Yes
Embedded options available No
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
Memory types supported by processor DDR4-SDRAM
PCI Express slots version 5.0
Warnings Avoid contact with liquids.
Supported instruction sets AVX 2.0
On-board graphics card outputs supported DisplayPort 1.4a

Dimensions and weights

Package width
122 cm
Package height
80 cm
Package length
110 cm

Product codes

EAN
5032037238410
Manufacturer code
BX80715G7400
