ASUS TUF GAMING B760M-E D4 Intel B760 LGA 1700 micro ATX

Main info

Processor socket LGA 1700 Ethernet LAN Yes

Product has been archived


Processor socket LGA 1700
Ethernet LAN Yes
Supported storage drive types HDD & SSD
Number of SATA III connectors 4
Number of storage drives supported 6
Processor manufacturer Intel
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1
Maximum internal memory 128 GB
Supported memory types DDR4-SDRAM
Memory slots type DIMM
USB 2.0 ports quantity 2
Unbuffered memory Yes
Supported storage drive interfaces M.2, SATA III
ATX Power connector (24-pin) Yes
DisplayPorts quantity 1
PCI Express x16 (Gen 4.x) slots 1
Headphone outputs 1
Number of memory slots 4
USB 2.0 connectors 2
Microphone in Yes
PS/2 ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
Ethernet LAN (RJ-45) ports 1
RAID support Yes
Wi-Fi No
12V power connector Yes
Motherboard chipset Intel B760
S/PDIF out connector Yes
Front panel audio connector Yes
Audio output channels 7.1 channels
USB 3.2 Gen 2 (3.1 Gen 2) connectors 1
Package weight 1.29 kg
Depth 244 mm
Width 244 mm
Number of HDDs supported 4
RGB LED pin header Yes
Motherboard chipset family Intel
Memory channels Dual-channel
HDMI ports quantity 1
Motherboard form factor micro ATX
PCI Express x1 (Gen 4.x) slots 1
Number of COM connectors 1
Component for PC
Package width 275 mm
CPU fan connector Yes
Package depth 265 mm
BIOS type UEFI AMI
Peripheral (Molex) power connectors (4-pin) 1
Number of chassis fan connectors 2
BIOS memory size 128 Mbit
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
EPS power connector (8-pin) Yes
Package height 68 mm
Non-ECC Yes
Warranty 36 (G)
Ethernet interface type 2.5 Gigabit Ethernet
Windows operating systems supported Windows 10 x64
Compatible processor series Intel® Celeron®
RAID levels 10
Supported memory clock speeds 4266

Dimensions and weights

Package width
280 cm
Package height
370 cm
Package length
300 cm

Product codes

EAN
4711387131404
Manufacturer code
90MB1E90-M0EAY0
