Power Supply - Akyga Ak-b1-500e 500w 20+4 Pin, Gray

Main info

The Akyga AK-B1-500E PSU has a total power output of 500 W and supports ATX motherboard form factors. It features a combined +3.3V power output of 250 W, with max output currents of 30 A for +3.3V, 21 A for +12V, and 34 A for +5V.

Product has been archived

Power Supply - Akyga Ak-b1-500e 500w 20+4 Pin, Gray

The Akyga AK-B1-500E is a high-performance power supply unit (PSU) designed for PC systems with a total power output of 500 W and support for various motherboard form factors.

Key Features
  • Total Power Output: 500 W
  • Input Voltage: 220 V AC
  • Operating Temperature: 5 - 50 °C
  • Mean Time Between Failures (MTBF): 100000 h

Technical details
Sustainability certificates RoHS
Design
On/off switch Yes
Product colour Grey
Fan diameter 12 cm
Number of fans 1 fan(s)
Power
Combined power (+5V) 250 W
Combined power (+3.3V) 250 W
Max output current (+3.3V) 30 A
Total power 500 W
Power Factor Correction (PFC) type Passive
Combined power (+12V) 252 W
Max output current (+12V) 21 A
Max output current (+5V) 34 A
Input current 5 A
AC input voltage 220 V
Operational conditions
Operating temperature (T-T) 5 - 50 °C
Weight & dimensions
Width 150 mm
Weight 1.01 kg
Height 85 mm
Depth 140 mm
Performance
Power supply unit (PSU) form factor ATX
ATX version 2.31
Purpose PC
Supported motherboard form factors ATX
Mean time between failures (MTBF) 100000 h
Packaging data
Package width 160 mm
Manual Yes
Package depth 220 mm
Package weight 1.09 kg
Package type Box
Package height 95 mm
Packaging content
Cables included Peripheral (Molex) to SATA 3.3, SATA
Ports & interfaces
Peripheral (Molex) power connectors (4-pin) 2
PCI Express power connectors (6-pin) 1
EPS power connector (8-pin) No
Motherboard power connector 20+4 pin ATX
PCI Express power connectors (6+2 pin) 1
Number of SATA power connectors 3
SATA power cable length 300 mm
Peripheral (Molex) power cable length 300 mm
Other features
Number of cables 4
Voltage tolerance 70%
Fan controller Yes
Warranty card Yes

Width 150 mm
Height 85 mm
Length 140 mm
Product Weight 1010 g
Country PL

Dimensions and weights

Gross weight
1.09 kg
Package width
16 cm
Package height
9.5 cm
Package length
22 cm

Product codes

EAN
5901720133236
Manufacturer code
AK-B1-500E
