Motherboard ROG STRIX B850-F GAMING WIFI

359 €

Monthly payment starting from 12,24 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

Add to cart

Delivery in 7-10 working days

Free delivery

14 14 days return policy when purchasing online

ROG STRIX B850-F Gaming WiFi

The ROG Strix B850-F Gaming WiFi is built to dominate with AMD Ryzen 9000 series desktop processors. Its advanced power design and AI solutions ensure maximum performance. Furthermore, support for a total of 19 USB ports, including 20Gbps USB, as well as 7Gbps WiFi and 2.5Gbps Ethernet, ensures cutting-edge connectivity. This motherboard delivers the power and speed necessary for elite gaming and the demands of advanced AI PC applications.


Model ROG STRIX B850-F GAMING WIFI
CPU socket Socket AM5
Processor family AMD Ryzen 9
Processor family AMD Ryzen 5
Processor family AMD Ryzen 7
Integrated CPU No
Chipset manufacturer AMD
Memory type DDR5
Number of DDR5 slots 4
Memory bus frequency 8000 MHz
Max memory size 192
Expansion slots 2 x PCIe 5.0 x16
Expansion slots 4 x M.2
Expansion slots 1 x PCIe 4.0 x 16
Max. number of SATA devices 2
RAID Yes
Network interface Wi-Fi 802.11a/b/g/n/ac/ax/be
Network interface Bluetooth
Network interface 1 x 10/100/1000/2500 Mbit/s
USB ports at back panel 12
USB ports on motherboard 7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 5
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 5
FireWire (IEEE 1394) No
COM connector / port No
LPT connector / port No
External connectors 1 x USB 3.2 Gen 2x2 Type-C
External connectors 1 x Przycisk Clear CMOS
External connectors 1 x Wi-Fi Module
External connectors 1 x USB 3.2 Gen 2 Type-C
External connectors 2 x USB 3.2 Gen 2 Type-A
External connectors 4 x USB 3.2 Gen 1 Type-A
External connectors 4 x USB 2.0
External connectors 1 x S/PDIF
External connectors 1 x DisplayPort
External connectors 1 x HDMI
External connectors 1 x Line Out
External connectors 1 x MIC
External connectors 1 x RJ-45
External connectors 1 x Flash BIOS Button
Onboard connectors 3 x Addressable LED
Onboard connectors 1x CPU/DRAM overvoltage jumper
Onboard connectors 1 x Front panel audio header
Onboard connectors 1 x System panel header
Onboard connectors 1 x Thermal sensor connector
Onboard connectors 1 x Power button
Onboard connectors 1 x Thunderbolt header
Onboard connectors 1 x 4pin CPU fan
Onboard connectors 1 x 4pin wentylator OPT CPU
Onboard connectors 4 x 4pin Chassis fan
Onboard connectors 1 x 4-pin water-pump-fan
Onboard connectors 2 x 8pin 12V
Onboard connectors 1 x 24pin ATX zasilanie
Onboard connectors 4 x M.2
Onboard connectors 2 x SATA III 6Gb/s
Onboard connectors 2 x USB 2.0/1.1 header
Onboard connectors 1 x USB 3.2 Gen 1 Type-A
Onboard connectors 1 x USB 3.2 Gen 2 Type-C
Form factor ATX
Supported operating systems Windows 11
Designation
Chipset type AMD B850 Chipset
Graphics 1 x DisplayPort* 1 x HDMI port** * Supports up to 8K@30Hz according to the DisplayPort 1.4 specification ** Supports 4K@60Hz according to the HDMI 2.1 specification *** VGA resolution support depends on the resolution of the processor or graphics card.
Network interface Ethernet 1 x Intel 2.5Gb Ethernet ASUS LANGuard Wireless and Bluetooth Wi-Fi 7 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6 GHz frequency bands Supports Wi-Fi 7 160 MHz band, up to 2.9 Gbps transfer speeds. Bluetooth v5.4
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Dimensions 30.5 cm x 24.4 cm
Accessories included 2 x SATA 6Gb/s Cable ASUS WiFi Q-Antenna Cable Tie Pack M.2 Q-Latch Pack M.2 Q-Slide Pack ROG Keychain ROG Strix Stickers 4 x M.2 Rubber Bands Quick Start Guide
Other information WOL management via PME, PXE
Detailed data on disk/drive interfaces AMD Ryzen 7000 & 9000 Series Desktop ProcessorsM.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode)M.2_2 (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode)AMD Ryzen 8000 Series Desktop ProcessorsM.2_1 (Key M), type 2242/2260/2280 (supports PCIe
Sound card ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080* Impedance sensing for front and rear headphone outputs Supports: jack detection, streaming, and front-panel microphone jack remapping High-quality stereo playback output with a 120 dB S
Special functions Extreme Engine Digi+  5K Black metallic concentrates ASUS Q-Design  M.2 Q-Latch  M.2 Q-Release  M.2 Q-Slide  PCIe Slot Q-Release Slim (with PCIe SafeSlot)  Q-Antenna  Q-Dashboard  Q-DIMM  Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow-g
Software ROG exclusive software ROG CPU-Z Dolby Atmos ASUS exclusive software Armoury Crate AIDA64 Extreme (60-day free trial) Aura Creator Aura Sync Fan Xpert 4 GameFirst HWiNFO Power Saving ASUS DriverHub ASUS GlideX TurboV Core Adobe Creative Cloud (free trial)

Dimensions and weights

Gross weight
0.87 kg
Package width
36 cm
Package height
7 cm
Package length
27.5 cm

Product codes

EAN
4711387771013
Manufacturer code
KBASUAA8B850A01

Manufacturer

Manufacturer
ASUSTeK Computer Inc., Li-De Rd., 15, Taipei, 112, TW, investor@asus.com
Responsible person in the EU
Asus Europe B.V., Paasheuvelweg 25, Amsterdam, 1101, NL, advance.rma.eu@asus.com
