Home page » Computers & IT»Computer components»Mainboards»GIGABYTE H610M S2H V2 DDR4 Motherboard - Supports Intel Core 14th CPUs, 6+1+1 Hybrid Phases Digital

GIGABYTE H610M S2H V2 DDR4 Motherboard - Supports Intel Core 14th CPUs, 6+1+1 Hybrid Phases Digital

FREE SHIPPING
WITHIN ESTONIA!

94,99 €

Monthly payment starting from 2,84 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

Add to cart

Delivery in 7-10 working days

Delivery starting at 0 €

14 14 days return policy when purchasing online


Bundled software Norton® Internet Security (OEM version) LAN bandwidth management software
ATX Power connector (24-pin) Yes
Cooling type Active
BIOS type UEFI AMI
Desktop Management Interface (DMI) version 2.7
On-board graphics card Yes
Number of M.2 (M) slots 1
Headphone outputs 1
Total number of SATA connectors 4
HDMI ports quantity 1
Number of COM connectors 1
Package width 265 mm
USB 2.0 ports quantity 4
Front panel connector Yes
Package depth 265 mm
TPM connector Yes
EPS power connector (8-pin) Yes
Memory channels Dual-channel
Serial port headers 1
Graphics card family Intel
Package weight 857 g
Memory slots type DIMM
Number of storage drives supported 5
VGA (D-Sub) ports quantity 1
Width 230 mm
RGB LED pin header Yes
Battery type CR2032
Maximum internal memory supported by processor 64 GB
PS/2 ports quantity 2
CPU fan connector Yes
PCI Express x1 slots 1
Wi-Fi No
12V power connector Yes
Warranty period 3 year(s)
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Battery technology Lithium-Manganese Dioxide (LiMnO2)
Supported processor sockets LGA 1700
Depth 215 mm
Package height 54 mm
Clear CMOS jumper Yes
Height 35 mm
Ethernet LAN Yes
Number of chassis fan connectors 2
Processor manufacturer Intel
Component for PC
Supported memory types DDR4-SDRAM
Number of HDDs supported 4
DVI-D ports quantity 1
Maximum number of SMP processors 1
ACPI version 5.0
Products per shipping (inner) case 1 pc(s)
Number of memory slots 2
Number of battery cells 1
Microphone in Yes
Battery weight 3 g
Batteries included Yes
Clear CMOS button Yes
Processor socket LGA 1700
System Management BIOS (SMBIOS) version 2.7
BIOS memory size 128 Mbit
Ethernet interface type Gigabit Ethernet
Supported memory clock speed (max) 3200 MHz
ECC сompatibility ECC & Non-ECC
Lithium weight per battery 0.07 g
Supported storage drive interfaces M.2, SATA
Maximum internal memory 64 GB
Audio output channels 7.1 channels
Unbuffered memory Yes
Motherboard form factor micro ATX
USB 2.0 connectors 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1
Motherboard chipset Intel H610 Express
Country of origin China
Number of SATA III connectors 4
Motherboard chipset family Intel
Graphics card HD Graphics
DisplayPorts quantity 1
DirectX version 12.0
PCI Express x16 slots 1
Product colour Bronze
Supported storage drive types HDD & SSD
HDCP Yes
Power source type ATX
On-board graphics card model Intel® HD Graphics
Ethernet LAN (RJ-45) ports 1
Front panel audio connector Yes
Warranty 24 (G)
Supported DIMM module capacities 8GB
Windows operating systems supported Windows 11 x64
Compatible processor series Intel® Core™ i3
PC health monitoring Voltage
Supported memory clock speeds 3000
Supported memory module capacities 12GB

Dimensions and weights

Package width
265 cm
Package height
270 cm
Package length
55 cm

Product codes

EAN
4719331851958
Manufacturer code
H610M S2H V2 DDR4
