Special features |
The specification and description are for illustrative purposes only. |
Safety warning |
Do not open the appliance housing without the appropriate tools and technical knowledge. |
Bundled software |
Bitdefender Internet Security |
Number of storage drives supported |
6 |
Power supply input voltage |
100-240 V |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
Display included |
No |
NVMe |
Yes |
Number of SATA III connectors |
4 |
Graphics card Open GL support |
Yes |
Microphone in |
Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
1 |
VESA mounting |
No |
ECC |
No |
Antenna type |
2x2 |
SSD capacity |
1 TB |
DVI port |
No |
Discrete GPU manufacturer |
AMD |
Number of processors installed |
1 |
Graphics card HDMI ports quantity |
1 |
Headphone outputs |
1 |
Storage media |
SSD |
Discrete graphics card memory |
16 GB |
Processor model |
7600X3D |
Weight |
10 kg |
Processor threads |
12 |
Ethernet LAN |
Yes |
Processor frequency |
4.1 GHz |
80 PLUS certification |
80 PLUS Bronze |
Product type |
PC |
Total storage capacity |
1 TB |
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
Mouse included |
No |
On-board graphics card model |
AMD Radeon Graphics |
Processor cores |
6 |
NVIDIA GameWorks VR |
No |
Internal memory |
32 GB |
USB 2.0 ports quantity |
4 |
Maximum internal memory |
192 GB |
Memory layout (slots x size) |
2 x 16 GB |
Bluetooth |
Yes |
Refurbished |
No |
Internal memory type |
DDR5-SDRAM |
Graphics card DisplayPorts quantity |
3 |
NVIDIA G-SYNC |
No |
Memory clock speed |
6000 MHz |
Discrete graphics card |
Yes |
Water cooling system |
No |
Width |
230 mm |
S/PDIF out port |
No |
Motherboard chipset |
AMD B650 |
Processor family |
AMD Ryzen™ 5 |
Bluetooth version |
5.2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
RGB backlighting |
Yes |
Height |
500 mm |
Intel® Optane™ Memory module installed |
No |
SSD interface |
PCI Express |
On-board GPU manufacturer |
AMD |
Processor manufacturer |
AMD |
Discrete graphics memory type |
GDDR6 |
On-board graphics card family |
AMD Radeon Graphics |
Number of 2.5" bays |
5 |
Number of rear audio ports |
6 |
Market positioning |
Gaming |
Line-out |
Yes |
Combo headphone/mic port |
Yes |
Powered by |
VIEW |
Viewing window |
Yes |
Housing material |
Metal, Plastic, Tempered glass |
Line-in |
Yes |
Number of storage drives installed |
1 |
PCI Express x16 (Gen 4.x) slots |
2 |
Depth |
440 mm |
AMD FreeSync |
Yes |
Number of front USB ports |
2 |
Intel® Thunderbolt 5 |
No |
Audio output channels |
7.1 channels |
Processor generation |
AMD Ryzen 7000 Series |
Card reader integrated |
No |
Cabling technology |
10/100/1000Base-T(X) |
Processor boost frequency |
4.7 GHz |
TV tuner integrated |
No |
HDMI ports quantity |
2 |
Total SSDs capacity |
1 TB |
Discrete graphics card model |
AMD Radeon RX 9070 |
Fiber NIC port (Flex I/O) |
No |
Memory channels |
Dual-channel |
Chassis type |
Midi Tower |
On-board graphics card |
Yes |
Processor cache |
96 MB |
Number of rear USB ports |
8 |
Number of 3.5" bays |
2 |
M.2 SSD size |
2280 (22 x 80 mm) |
Processor cache type |
L3 |
Motherboard form factor |
micro ATX |
Operating system installed |
No |
Number of discrete graphics cards |
1 |
PCI Express x1 (Gen 3.x) slots |
1 |
Product colour |
Black |
Power supply |
750 W |
Optical drive type |
No |
SSD form factor |
M.2 |
Number of front audio ports |
1 |
Wi-Fi |
Yes |
DisplayPorts quantity |
4 |
Intel® Thunderbolt 4 |
No |
USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
CUDA |
No |
Processor socket |
Socket AM5 |
Number of SSDs installed |
1 |
Processor base power |
65 W |
DC-in jack |
No |
Memory slots |
4x DIMM |
Virtual Reality (VR) ready |
Yes |
Keyboard included |
No |
Built-in microphone |
No |
Warranty |
36 (G) |
Internal components |
ASUS TUF GAMING B650M-PLUS WIFI / AMD Radeon RX 9070 / WD Blue SN580 / Phanteks XT View Window |
Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
Ethernet LAN data rates |
100 |
