HUAWEI WiFi AX3 Pro Quad-Core WS7200 white

Main info

Usher in the Era of Wi-Fi 6 Wi-Fi 5 is the standard used by most devices today, while Wi-Fi 6 (802.11ax) is the new standard that’s gradually coming into smart devices in recent years. Wi-Fi 6 has made several improvements over Wi-Fi 5 to cope with t

Product has been archived

Usher in the Era of Wi-Fi 6
Wi-Fi 5 is the standard used by most devices today, while Wi-Fi 6 (802.11ax) is the new standard that’s gradually coming into smart devices in recent years. Wi-Fi 6 has made several improvements over Wi-Fi 5 to cope with the increasing demand for faster and more efficient Wi-Fi.

Speed Up HUAWEI Wi-Fi 6-Enabled Phones with HUAWEI Wi-Fi 6 Plus
AX3 and Wi-Fi 6-enabled HUAWEI phones are the perfect pair because both are equipped with HUAWEI's self-developed Wi-Fi chipset, which support 160 MHz frequency bandwidth. This lays the foundation for Chipset Synergy, bringing out optimal speed and efficiency.

Signal Can Go Through One More Wall with HUAWEI Wi-Fi 6 Plus
HUAWEI Wi-Fi 6-enabled phones are able to send 6dB stronger signals back to AX3 in stable, 2 MHz narrow bandwidth using Dynamic Narrow Bandwidth technology, which is based on Chipset Synergy. The wireless signals can penetrate solid objects like walls and floors easily. This means that the phone will have good reception of the Wi-Fi signal even when connecting from upstairs or somewhere far from the router.

Fast Speed beyond Your Imagination
You will be impressed with the blazing fast speed delivered by AX3. Thanks to 1024-QAM and 160 MHz frequency bandwidth, its theoretical speed can reach up to 3000 Mbps (574 Mbps on a 2.4 GHz band and 2402 Mbps on a 5 GHz band).1 The quad-core Gigahome CPU allows AX3 to best unleash its speed. At such speed, what used to be taken for granted, like buffering and lagging, will be a thing of the past. Enjoy smooth streaming and gaming like never before.

Multiple Connections.
Smooth Connections.
Unlike traditional routers, you can connect a multitude of devices to AX3 with greater efficiency. Supporting OFDMA multi-user technology, it is capable to send data to multiple devices simultaneously (max. 4 devices on 2.4 GHz, max. 16 devices on 5 GHz). The highly powered quad-core Gigahome CPU also ensures smooth running of the processor. And, it is capable of connecting up to 128 devices overall on dual bands.5 No matter how crowded the space, it will serve different users and devices promptly.

Larger Bandwidth with 160 MHz
As AX3 supports 160 MHz, when connecting AX3 to devices supporting 160 MHz, like top-of-the-line HUAWEI Wi-Fi 5-enabled smart phones, tablets and laptops, the internet speed would increase 60% and more.6 This offers you an unprecedented, lag-free experience on mobile devices.

Effortless Connection, Revolutionary Experience
Huawei Share allows you to connect AX3 to your smart phone with a simple tap. Whether throwing a home party or celebrating festivals with friends and families, this router will remember the password for you and let the guests you trust, connect to it easily.

Multi-router mesh networking7 enables greater Wi-Fi coverage
The HUAWEI WiFi AX3 supports wireless networking, network cable networking,and the hybrid networking of wireless and network cables. After networking, multiple routers are automatically grouped under one Wi-Fi name, and the optimal Wi-Fi is automatically selected based on the device's location. The HUAWEI WiFi AX3 can network with old HUAWEI Wi-Fi routers (with H button) to expand network coverage at home.

Protect Your Network with Huawei HomeSec™
Enabled by TEE (Trusted Execution Environment) and Microkernel, AX3 offers a secure area inside its main processor, where both software and hardware are used to protect the data. It is also CC EAL5 certified, meaning it could operate safely in a commercial environment, offering great security assurance to your devices.
WAN connection
Ethernet WAN: Y
DSL WAN: N
SIM card slot: N
3G/4G USB modem compatibility: N
Wireless LAN features
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max): 2976 Mbit/s
Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band): 574 Mbit/s
WLAN data transfer rate (second band): 2402 Mbit/s
Channels quantity: 2 channels
Ports & interfaces
USB port: N
Ethernet LAN (RJ-45) ports: 3
DC-in jack: Y
Memory card slot(s): N
Mobile networking
3G: N
4G: N
Networking
Ethernet LAN: Y
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.11v
VPN Passthrough: Y
Protocols
DHCP client: Y
DHCP server: Y
Antenna
Antenna type: External
Antennas quantity: 4
Antenna gain level (max): 5 dBi
Management features
Reset button: Y
Security
Security algorithms: WPA3
Guest access: Y
Parental control: Y
DoS attack prevention: Y
Filtering: Y
MAC address filtering: Y
DMZ support: Y
IP address filtering: Y
Design
Housing material: Plastic
Colour of product: White
Product type: Tabletop router
Wall mountable: Y
LED indicators: Status
Power
Power source type: AC
AC input frequency: 50/60 Hz
AC input voltage: 220 - 240 V
Weight & dimensions
Width: 225 mm
Depth: 159.2 mm
Height: 39.7 mm
Weight: 403 g
Features
Built-in processor: Y
Processor frequency: 1400 MHz
Processor cores: 4
Packaging data
AC adapter included: Y
Cables included: LAN (RJ-45)
Quick start guide: Y
Package type: Box

Product codes

EAN
6972453163820
Manufacturer code
WS7200-20
