"8+2P TP-Link Omada SG3210 M RM"

Main info

Product has been archived

"TP-Link Omada SG3210. Switch-Typ: Managed, Switch-Ebene: L2/L3. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000), Anzahl der basisschaltenden RJ-45 Ethernet Ports: 8, Konsolen-Port: RJ-45/micro-USB. MAC-Adressentabelle: 8000 Eintragungen, Routing-/Switching-Kapazität: 20 Gbit/s. Netzstandard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE.... Rack-Einbau, Formfaktor: 1U"
Switch-Typ Managed
Switch-Ebene L2/L3
MIB Unterstützung Yes
Anzahl der basisschaltenden RJ-45 Ethernet Ports 8
Basic Switching RJ-45 Ethernet Ports-Typ Gigabit Ethernet (10/100/1000)
Menge SFP-Modul-Steckplätze 2
Konsolen-Port RJ-45/Micro-USB
IPv4-Routen 48
IPv6-Routen 48
Virtuelle LAN-Funktionen Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Anzahl der VLANs 4000
Routing-/Switching-Kapazität 20 Gbit/s
Transferrate 14,9 Mpps
MAC-Adressentabelle 8000 Eintragungen
Anzahl IP-Schnittstellen 16
Jumbo-Frames 9000
Datenpaket-Pufferspeicher 4,1 MB
DHCP-Funktionen DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
Authentifizierung MAC-basierte Authentifizierung, Port-basierte Authentifizierung
Autentifizierungstyp RADIUS
Management-Protokolle SNMPv1/v2c/v3, SNTP
IPv4 & IPv6-Funktionen IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert
Formfaktor 1U
Produktfarbe Schwarz
Mindestsystemvoraussetzungen Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux.
Energiequelle AC
AC Eingangsspannung 100 - 240 V
AC Eingangsfrequenz 50/60 Hz
Stromverbrauch (max.) 6,84 W
Betriebstemperatur 0 - 40 °C
Temperaturbereich bei Lagerung -40 - 70 °C
Relative Luftfeuchtigkeit in Betrieb 10 - 90%
Luftfeuchtigkeit bei Lagerung 5 - 90%
Wärmeableitung 23,33 BTU/h
Quality of Service (QoS) Support Ja
Web-basiertes Management Ja
Cloud-verwaltet Ja
ARP-Inspektion Ja
Konfiguration der Standorteinstellungen (CLI) Ja
Systemereignisprotokoll Ja
Netzstandard IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G-Unterstützung Nein
Port-Spiegelung Ja
IP-Routing Ja
Unterstützung Datenflusssteuerung Ja
Link Aggregation Ja
Broadcast-Sturmkontrolle Ja
Ratenbeschränkung Ja
Spannbaum-Protokoll Ja
Head-of-Line (HOL)-Blocking Ja
VLAN-Unterstützung Ja
Store-and-Forward Ja
Statische Route Ja
Jumbo Frames Unterstützung Ja
Zugriffkontrollliste Ja
IGMP-Snooping Ja
MAC Adressen Filtern Ja
Statische Anschlusssicherheit Ja
SSH-/SSL-Unterstützung Ja
Loop Protection Ja
BPDU-Filterung/Schutz Ja
IP-MAC-Portbindung Ja
Multicast Unterstützung Ja
Multicast Listener Discovery (MLD) Snooping Y
GARP VLAN Registration Protocol (GVRP) Ja
Rack-Einbau Ja
LED-Anzeigen Ja
Upgradefähige Firmware Ja
Ventilatorlos Ja
Netzteil enthalten Ja
Power over Ethernet (PoE) Nein
Schnellstartübersicht Ja
Benutzerhandbuch Ja
Betriebsanleitung Ja
Rackmontageset Ja

Dimensions and weights

Gross weight
2.023 kg
Package width
29.4 cm
Package height
4.4 cm
Package length
18 cm

Product codes

EAN
6935364006396
