Network Switch - Tenda Sg105m Black

Main info

5 Gigabit Ethernet ports and operating temperature of 0 - 40 °C. Power consumption (max) is 1.7 W with supported networking standards including IEEE 802.3ab and IEEE 802.3x.

Product has been archived

Tenda SG105M

The Tenda SG105M network switch is a compact and feature-rich Gigabit Ethernet switch designed for small to medium-sized networks.

Key Features
  • 5 Gigabit Ethernet ports
  • Auto MDI/MDI-X support for hassle-free cable management
  • Jumbo frames support up to 15 KB
Technical Specifications
  • Operating temperature: 0 - 40 °C
  • Storage temperature: -40 - 70 °C
  • Power consumption (max): 1.7 W

Design
LED indicators Link, Power, Activity
Wall mountable Yes
Product colour Black
Housing material Plastic
Rack mounting No
Stackable No
Power
AC input voltage 100 - 240 V
Power consumption (max) 1.7 W
Power source AC
Power supply included Yes
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage relative humidity (H-H) 5 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 10 - 90%
Weight & dimensions
Width 82 mm
Depth 52 mm
Height 22 mm
Network
Networking standards IEEE 802.3ab, IEEE 802.3x, IEEE 802.3u
Auto MDI/MDI-X Yes
Copper ethernet cabling technology 100BASE-TX, 10BASE-T, 1000BASE-T
Full duplex Yes
Cable types supported Cat3, Cat5, Cat5e
MAC address auto-aging supported Yes
MAC address auto-learning supported Yes
Packaging data
Quick start guide Yes
Ports & interfaces
Power connector DC-in jack
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 5
Console port RJ-45
Gigabit Ethernet (copper) ports quantity 5
Data transmission
Switching capacity 10 Gbit/s
Jumbo frames support Yes
Forwarding rate 7.44 Mpps
MAC address table 2000 entries
Packet buffer memory 1 MB
Jumbo frames 15
Store-and-forward Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) No

Width 100 mm
Height 40 mm
Length 200 mm
Product Weight 500 g
Country CN

Dimensions and weights

Gross weight
0.7 kg
Package width
12 cm
Package height
6 cm
Package length
22 cm

Product codes

EAN
6932849436389
Manufacturer code
SG105M
