Hytera Z1p - TETRA handheld radio

Small, secure & powerful

Hytera Z1p is an ultra-slim TETRA handheld radio with a full keypad. It was developed in complete
correspondence with the open ETSI standard TETRA and combines compact form with outstanding radio
properties.

Highlights:

  • Ultra-slim radio (only 23 mm) with transmitting power of 3 Watts
  • Secure TETRA encryption and tamper protection (Tamper Proof)
  • Large 1.8-inch color display, easy to read even in bright sunlight
  • Robust and waterproof: In accordance with MIL-STD-810 C/D/E/F/G and degree of protection IP67
  • Device interface for audio and data accessories, plug & play, platform for Java™ applications

    • Compact design and high transmitting power

    The Z1p from Hytera combines compact design with extensive TETRA functionality, integrated in a housing
    that is only 23 mm thick. Thanks to its small dimensions, this handheld radio is perfectly suited to
    concealed applications. In spite of its compact design, the Z1p transmits with a power of up to 3 Watts.

    Dust- and waterproof to IP67

    Even under harsh operating conditions Z1p boasts excellent features. The device fulfills the requirements
    of protection class IP67 and can be submerged in water at a depth of 1 meter for at least 30 minutes.
    The Z1p meets the requirements of the US-American MIL - STD - 810 C / D / E / F / G standard and passed
    the HALT tests (Highly Accelerated Life Test).

    Extensive security functions

    TETRA security features such as Air Interface Encryption and End-to-End encryption reliably protect the
    radio communication. The built-in protection against tampering (tamper-proof) protects stored TETRA
    algorithms/keys against direct attacks.

    Intelligent antenna design

    The integrated radio and GPS antenna provides high comfort and even better features. Both operating
    buttons of Z1p are separated from each other via the antenna so that operating errors are virtually
    excluded even with gloves or under poor light conditions.

    Immediate and direct communication

    The Z1p offers fast access to the TETRA mobile radio network and the services. It was developed according
    to the regulations of the ETSI TETRA standard and is therefore compatible with infrastructures and terminals
    from various manufacturers.

    Various functions

    Besides the voice and data communication, the Z1p offers many additional functions: GPS, encryption,
    programmable buttons, etc. In addition, the handheld mobile radio features a connection for expansions
    and accessories.

    Operating mode

  • Trunked radio mode (TMO): Communication via the TETRA radio network (semi-duplex and duplex mode)
  • Direct mode (DMO): Direct communication between the radios (semi-duplex)
  • Support for DMO Repeater and TMO / DMO Gateway communication: Extended range for DMO communication
  • Operation as DMO Repeater*: Operating mode TETRA type 1A

    • Group calls

    - Group calls with defined, pre-emptive or emergency call priority
    - Dynamic Group Number Assignment (DGNA), broadcast call (group, TMO), Talking Party Identification in group call

    Individual call

    - Individual call semi-duplex and duplex (TMO)
    - Individual call with defined, pre-emptive or emergency call priority
    - Calling Line Identification Presentation (CLIP)
    - Calls to telephone networks (PSTN / PABX) (TMO)
    - PSTN / PABX individual call full duplex and semi-duplex
    - DTMF
    - Calling Line Identification Presentation (CLIP)

    Additional call services

    - Callout

    Security functions

  • Authentication
  • Air Interface Encryption (TEA1, TEA2 *, TEA3, TEA4)
  • End-to-end encryption (E2EE)
  • TETRA security classes 1, 2, 3 – non-encrypted, static encryption (SCK), dynamic encryption (DCK/CCK)
  • Key distribution via air interface (OTAR)
  • Enable/Disable via air interface, temporary/permanent
  • Ambience Listening
  • Access control with PIN / PUK code
  • Protection against tampering (tamper-proof)*

    • Security functions for the user

  • Orange emergency key
  • Lone worker function
  • Tilt alarm
  • Silent alarm
  • Call barring and key lock
  • Configuration protection / configuration password
  • TX Inhibit (TXI)

    • Functions of the user interface

  • 18 programmable keys for direct access to individual functions (short keys) and 4-ways navigation key
  • Call log: Missed/answered calls, dialed numbers
  • Flexible dialing (e.g. direct dialing, redialing, dialing lists etc.)
  • Two microphones for semi-duplex and duplex calls
  • Wireless BT connection to audio and PTT devices with automatic search and recognition
  • Adjustable display brightness
  • Many international languages already available, can be upgraded
  • GPS positioning based on ETSI LIP or NMEA protocol
    • - Completely programmable position updates - Transmission of position information in case of an emergency call
  • Clock synchronization via GPS / SAT, radio network or local time
  • PEI interface
  • Energy saving mode
  • Automatic cell re-ѕelection without call interruption (handover)
  • Programming of ѕelectable networks (TMO, DMO)
  • Programming of ѕelectable gateways PSTN / PABX
  • Customizable alarm tones
  • Radio User Assignment (RUA)

    • Data / message services

  • Short data service (SDS) – types 1, 2, 3, 4 and TL
  • Concatenated SDS (Long SDS) and Flash SDS
  • Status message/ text message
  • Notification on new messages during calls
  • Packet Data Service (packet data, single-slot, multi-slot)
  • Java™ platform MIDP 2.0


    • The features marked with * are available in future versions of the Z1p.
