IP Network Camera 5MP HFW3549T1-AS-PV-S3 3.6mm

419 €

Monthly payment starting from 14,28 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

IP camera AI active deterrence 5MP Full Color with built-in microphone, speaker, spotlight and alarm. Double lighting IR+LED up to 30m. Two-color flashing alarm. 1/2.7” inch CMOS sensor. 5MP (2592×1944) 1~20fps. Fixed lens: 3.6mm F1.0 viewing angle 78°. H.265+/H.265/H.264. BLC, HLC, WDR 120dB, ROI, IVS, AI, SSA, SMD 3.0, PoE, corridor mode. 3D-NR: noise reduction technology. SD memory port max. 256GB. IP67 waterproof, suitable for outdoor and indoor conditions. Watermark for various observation scenes. 3 axis adjustment. Supports ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P standard. Model: IPC-HFW3549T1-AS-PV-S3 3.6mm.
Add to cart

Delivery in 7-10 working days

Free delivery

14 14 days return policy when purchasing online

IP camera HFW3549T1-AS-PV-S3. 5MP

Short description:

IP camera AI active deterrence 5MP Full Color with built-in microphone, speaker, spotlight and alarm. Double lighting IR+LED up to 30m. Two-color flashing alarm. 1/2.7” inch CMOS sensor. 5MP (2592×1944) 1~20fps. Fixed lens: 3.6mm F1.0 viewing angle 78°. H.265+/H.265/H.264. BLC, HLC, WDR 120dB, ROI, IVS, AI, SSA, SMD 3.0, PoE, corridor mode. 3D-NR: noise reduction technology. SD memory port max. 256GB. IP67 waterproof, suitable for outdoor and indoor conditions. Watermark for various observation scenes. 3 axis adjustment. Supports ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P standard. Model: IPC-HFW3549T1-AS-PV-S3 3.6mm.

Brief technical characteristics:

• 5MP FULL-COLOR dome IP camera with IR+LED lighting and integrated microphone.
• IVS functions: crossing the line, penetrating the perimeter.
• AI: Human recognition function, face detection, car recognition function, perimeter protection; Smart Motion Detection (SMD 3.0).
• 1/2.7” inch 5MP FULL-COLOR CMOS sensor.
• 3.6mm fixed lens F1.0, lens viewing angle 78°(H), 58°(V), 102°(D).
• DORI: 78m (detection), 31.2m (tracking), 15.6m (recognition), 7.8m (detection).
• Integrated microphone.
• Audio compression: PCM; G.711a; G.711Mu; G.726; G.723.
• Video compression: H.265; H.264; H.264H; H.264B; MJPEG; Smart H.265+/ Smart H.264+; AI coding AI H.265, AI H.264.
• Scanning system: Progressive.
• 2x IR+LED lighting up to 30m.
• Remote control and live monitoring via Ethernet (WEB): IE (IE8/9/11), Chrome, Firefox.
• Free software for camera control (SMART PSS), video viewing and archiving using a computer network or the Internet.
• A free program that allows the user to monitor and view recordings of cameras from different objects, the program allows the image to be saved to the computer.
• Free software for monitoring via a mobile phone or a handheld computer (DSS mobile phone surveillance software) is suitable for phones: IPHONE, ANDROID, IPAD, GALAXY TAB, etc.
• The IP camera can be used with software from other companies (VMS Partners): ALNET SYSTEMS, AXXON, DiGiFORT, Exacq Technologies, Genetech, GeoVision, Lenel, milestone, NETvision, NUUO, OnSSI, QNAP, Surveon, UNISIGHT, Aimetis, Cathexis solutions, GEUTEBRUCK, CANON, KSENOS, Kentima Solutions AB, Softguard Tech, Innodep Inc., LuxRiot A&H Software House, Inc., Video Insight, Mirasys Ltd., SEEnergy Corp., Synology, Wavestore and others.
• Number of effective pixels: 2592 (H) × 1944 (V).
• Video resolution options available: 5M (2592 × 1944); 4M (2688 × 1520); 4M (2560×1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280×720); D1 (704×576/704×480); CIF (354×288/354×240).
• Compression rate: Main stream: 2592 × 1944 @1-20 fps, 2688 × 1520 @1-25 fps; Additional Stream: 704×576 @1-25fps/704×480@1-25fps; Optional Third Stream: 1920×1080 @1-25 fps.
• Bitrate: H.264: 3 kbps - 20480 kbps, H.265: 3 kbps - 20480 kbps.
• Min. illumination: 0.003 Lux @ F1.0, color, 30 IRE; 0.0003 Lux @ F1.0 -B/W, 30 IRE..
• Y/N: Day/Night function: Switches from color image to black and white.
• 3D-NR: noise reduction technology.
• Corridor mode (flip 0°/90°/180°/270°).
• ROI function (4 zones).
• S/N ratio >56dB.
• Electronic Shutter: Auto/Manual, 1/3s - 1/100,000s.
• White light balance: Auto/Manual, BLC / HLC / WDR 120dB.
• Video format: PAL.
• 10/100 Mb/s network socket (Ethernet -RJ45).
• Network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP, ONVIF (Profile S/Profile G/Profile T); CGI; Milestone, P2P.
• Recording: FTP, SFTP or NAS servers.
• Remote control: Monitoring, EPTZ digital zoom, system settings, File download, Preview, software update.
• Maximum user login at one time: 20.
• Internal memory: micro SD memory port max. 256GB.
• Privacy z those: 8.
• Alarm input: 1 channel (5mA 3V-5V DC).
• Alarm output: 1 channel (300mA 12V DC).
• Audio input: 1 channel RCA.
• Audio output: 1 channel RCA.
• Linking of alarms with light and sound effects is supported; red and blue light flashing alarm, 11 installed sounds.
• Operating temperature: -40°C~+60°C, 95% RH.
• 3-axis mechanism for camera adjustment (Pan:0°~360°; Tilt:0°~90°; Rotation:0°~360°).
• Moisture resistant IP67 suitable for outdoor and indoor conditions.
• Power supply: DC12V / PoE (802.3af).
• Power consumption: 2.4W (12V DC) / 3.1W (PoE), max. power consumption: 7.9W (12V DC); 9.7W (PoE).
• Dimensions: 288.4 mm x 94.4 mm x 84.7 mm.
• Weight: 1 kg.


Compatible mounts:
PFA130-E.
PFA135.
PFA152-E.


Width 94.4 mm
Height 288.4 mm
Length 84.7 mm
Product Weight 1000 g
