DS-2CD2183G2-LIS2U(2.8mm) Kamera IP

Main info

Product has been archived


Warranty 36 (F)
Mounting type Ceiling/wall
Gain control type Auto
Digest authentication Yes
Power consumption (Power over Ethernet (PoE)) 9.5 W
Video recording Yes
Heartbeat Yes
Audio codecs G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Languages support Multi
Web browser Yes
Password reset via email Yes
Number of sensors 1
Video motion detection Yes
Infra-red wavelength 850 nm
Password protection Yes
Active tampering alarm Yes
Day/night mode Yes
Recognize distance 16 m
Number of simultaneous live view channels 6 channels
User access level Administrator, Operator, User
Dynamic range 120 dB
Number of languages 33
Identify distance 8 m
Night vision Yes
Terminal block port Yes
Video streaming Yes
Infrared (IR) cut-off filter Yes
Behavior analysis Line crossing detection
Live view Yes
Number of lenses 1
Number of users 32 user(s)
Sensor type CMOS
Pixel counter Yes
Placement supported Indoor & outdoor
DC output voltage 12
IP address filtering Yes
Mirror Yes
Observe distance 33 m
DC output current 0.65 A
HTTPS encryption Yes
Fixed focal length 2.8 mm
Automatic Network Replenishment (ANR) Yes
Alarm input/output Yes
Audit log Yes
Number of microphones 2
Number of Privacy masking areas 8
Lens viewing angle, vertical 59°
Sample rates 8 - 48 kHz
Bit rate range 8 - 320 Kbit/s
Lens viewing angle, horizontal 108°
Lens viewing angle, diagonal 127°
International Protection (IP) code IP67
Noise reduction Yes
Height 97.6 mm
Weight 600 g
Networking standards IEEE 802.3af
Reset button Yes
Package width 150 mm
Number of cameras 1
Maximum memory card size 512 GB
Ethernet LAN Yes
Camera shutter speed 1/3 - 1/100000 s
Built-in HDD No
Power source type DC, PoE
Region of Interest (ROI) encoding Yes
Audio input channels 1.0 channels
Product colour White
Ethernet interface type Fast Ethernet
IK code IK10
Built-in microphone Yes
Ethernet LAN (RJ-45) ports 1
Back Light Compensation (BLC) Yes
Noise reduction technology 3D noise reduction
Operating temperature (T-T) -30 - 60 °C
Bit rate 32 Kbps - 16 Mbps
LED type IR/White
Package depth 150 mm
Package weight 840 g
Highlight Compensation (HLC) Yes
Optical sensor size 25.4 / 2.8 mm (1 / 2.8")
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Type IP security camera
Wi-Fi No
Tilt angle range 0 - 75°
Operating relative humidity (H-H) 0 - 95%
Connectivity technology Wired
Wide Dynamic Range (WDR) Yes
Storage relative humidity (H-H) 0 - 95%
Housing material Aluminium
Maximum aperture number 1.6
Total megapixels 8 MP
Angle of rotation 355°
Power consumption (max) 7.8 W
Audio output channels 1.0 channels
Security algorithms TLS
Detect distance 84 m
Diameter 12.2 cm
Package height 141 mm
Storage temperature (T-T) -30 - 60 °C
Form factor Dome
Progressive scan Yes
Signal-to-Noise Ratio (SNR) 52 dB
Pan range 0 - 355°
Minimum illumination 0 lx
Maximum resolution 3840 x 2160 pixels
Alarm output channels 1
Alarm input channels 1
Frame rate 30 fps
Card reader integrated Yes
Night vision distance 30 m
Bluetooth No
Video compression formats H.264
Compliance certificates CB
Compatible memory cards MicroSD (TransFlash)
Protection features Dust resistant
Warnings The product contains electronic components; do not dispose of with the normal household waste.
Supported graphics resolutions 1920 x 1080 (HD 1080)

Camera

Horizontal swivel
355°

Dimensions and weights

Package width
155 cm
Package height
150 cm
Package length
140 cm

Product codes

EAN
6942160459035
Manufacturer code
50181
