Hikvision Ultra Series DS-2CD3141G2E-I(2.8mm) Dome IP security camera Outdoor 2560 x 1440 pixels Cei

Main info

Product has been archived


Warranty 24 (G)
Type IP security camera
HTTPS encryption Yes
Progressive scan Yes
Sensor type CMOS
Observe distance 23 m
Wide Dynamic Range (WDR) Yes
DC output current 0.4 A
Day/night mode Yes
Back Light Compensation (BLC) Yes
Optical sensor size 25.4 / 2.9 mm (1 / 2.9")
Noise reduction technology 3D noise reduction
Region of Interest (ROI) encoding Yes
Detect distance 59 m
Maximum aperture number 2
Recognize distance 11 m
Identify distance 5 m
Video motion detection Yes
Number of cameras 1
Angle of rotation 360°
DC output voltage 12
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Minimum illumination 0 lx
Frame rate 30 fps
Fixed focal length 2.8 mm
LED type IR
Lens viewing angle, vertical 55.5°
Gain control type Auto
Web browser Yes
Number of users 32 user(s)
Highlight Compensation (HLC) Yes
IK code IK08
Placement supported Outdoor
Noise reduction Yes
Video streaming Yes
Built-in HDD No
Camera shutter speed 1/3 - 1/100000 s
Supported network protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS, UPnP, 802.1X
Total megapixels 4 MP
Human and vehicle targets classification Yes
Mounting type Ceiling/wall
Lens viewing angle, horizontal 99.5°
Digest authentication Yes
Pan range 0 - 360°
Number of simultaneous live view channels 6 channels
Signal-to-Noise Ratio (SNR) 52 dB
Lens viewing angle, diagonal 116.1°
Pixel counter Yes
User access level Administrator, Operator, User
Night vision Yes
Number of Privacy masking areas 4
Audit log Yes
Password reset via email Yes
Languages support Multi
Power consumption (Power over Ethernet (PoE)) 6.5 W
Infra-red wavelength 850 nm
Behavior analysis Intrusion detection, Line crossing detection
Video recording Yes
Heartbeat Yes
Number of sensors 1
Privacy protection Yes
Dynamic range 120 dB
Privacy masking Yes
Infrared (IR) cut-off filter Yes
Password protection Yes
Live view Yes
Number of lenses 1
Mirror Yes
Active tampering alarm Yes
Length 170.8 mm
Package weight 720 g
Connectivity technology Wired
Package width 134 mm
Maximum resolution 2560 x 1440 pixels
Power source type DC, PoE
Ethernet interface type Fast Ethernet
Operating temperature (T-T) -30 - 60 °C
Bluetooth No
Package height 108 mm
Product colour White
Bit rate 32 Kbps - 8 Mbps
Storage temperature (T-T) -30 - 60 °C
Tilt angle range 0 - 90°
Form factor Dome
Night vision distance 40 m
Power consumption (max) 5 W
Ethernet LAN Yes
Quality of Service (QoS) support Yes
Weight 520 g
Web-based management Yes
Height 84.7 mm
Storage relative humidity (H-H) 0 - 95%
Package depth 134 mm
International Protection (IP) code IP67
Operating relative humidity (H-H) 0 - 95%
Ethernet LAN (RJ-45) ports 1
Wi-Fi No
Video compression formats M-JPEG
Warnings The product contains electronic components; do not dispose of with the normal household waste.
Compliance certificates Federal Communications Commission (FCC)
Video formats supported H.264+
Image quality adjustment Sharpness
Housing material Plastic
Protection features Vandal proof
Supported graphics resolutions 640 x 480 (VGA)
Security algorithms EAP-MD5
Networking standards IEEE 802.3at

Camera

Horizontal swivel
360°

Dimensions and weights

Package width
145 cm
Package height
260 cm
Package length
90 cm

Product codes

EAN
6931847193393
Manufacturer code
311322255
