Camera InSight S485PI

Addional discount of 7%
will be applied in shopping cart
(min. 8€ purchase)
549 €

Monthly payment starting from 18,71 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

Warning: Last items in stock!

Add to cart

Delivery in 7-10 working days

Free delivery

14 14 days return policy when purchasing online

InSight S485PI VIGI 8MP IR Panoramic Turret Network Camera

  • 180° Panorama View with Huge Vision
  • 4K (8MP) Ultra HD and IR Range Up to 65.62 ft (20 m)
  • Red-Blue Warning Lights with Stronger Deterrence
  • People & Vehicle Analytics*2
  • Human & Vehicle Classification
  • Smart Detection
  • Smart Video Enhancement Technology
  • Audio and Alarm Interface Available
  • IP67 Weatherproof and IK10 Vandal Proof
  • H.265+ Compression Technology

General cameras require multiple units to cover blind spots in large spaces like hotel lobbies, playgrounds, intersections, and warehouses, raising costs. A single panoramic camera with 180° view and 4K resolution reduces installation, deployment, and maintenance costs while covering more area.

Powerful, Efficient Monitoring with Active Defense
Active Defense is a monitoring feature that uses deep learning algorithms or external alarm devices to trigger flashing lights and loud sounds in real time, deterring intruders. It also supports user-created custom voice audio.

Red-Blue Warning Lights with
Stronger Deterrence
Red-blue flashing lights are more effective than white lights and create a strong deterrent effect when paired with audio alarms.

Flexible Audio & Alarm Integration
The Audio In/Out and Alarm In/Out ports enable easy integration with external alarm or access control devices.

Instant Event Notifications
When the AI function detects an event or an external alarm device senses an event and sends a signal to the IPC, the alarm will trigger with alerts instantly sent to your phone.

VIGI AI Detection Technology

  • People & Vehicle Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, upper body color, vehicle type, making post-event search faster and easier.
  • Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications.

Smart Video Enhancement Technology

  • True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
  • Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
  • 3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
  • White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.


Type Panoramic
Type fixed dome camera
Resolution 4K Ultra HD (3840 x 2160)
Frames per second 30
Sensor 1/2.7" Progressive Scan CMOS
Lens Fixed Focal Lens Focal Length: 1.65 mm Aperture: F2.0 Lens Mount: M12
Viewing angle, vertical 86
Viewing angle, horizontal 180
Visual angle diagonal 180
Microphone Yes
Speakers built-in Yes
Two-way transmission Yes
Night mode Yes
Motion detection Yes
Security Password Protection HTTPS Encryption IP Address Filter Digest Authentication
Management, monitoring, configuration ONVIF API: Open Network Video Interface (Profile S/T/G) Simultaneous Live View 3 Main Streams & 3 Sub-Streams Client: VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS Cloud
Network protocols TCP/IP UDP ICMP HTTP HTTPS DHCP DNS RTSP NTP UPnP UDP SSL/TLS FTP/SFTP RTP IPv4 IPv6 ARP
Standards 802.3at
Video compression H.265
Video compression H.265+
Video compression H.264+
Video compression H.264
Memory card reader Yes
Memory standard SDXC
Memory standard SDHC
Memory standard SD
Wireless communication No
Connectors RJ-45
Connectors Audio in
Connectors Audio out
Connectors microSD
Protection class IP67
Impact protection IK10
Power supply 12V DC +/- 5%, Max. 18 W, 5.5 mm Coaxial Power Plug PoE: 802.3at, class 4, Max. 21 W
System Requirements Google Chrome 57 and above Firefox 52 and above Safari 11 and above Microsoft Edge 91 and above
Accessories included VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories
Color white
Dimensions 112.3 x 112.3 x 110.2 mm
Certificates CE NTRA KC FCC VCCI BSMI ONVIF
Designation
Environment requirements Operating Temperature: -30 to 60 °C Storage Temperature: -40 °C to 60 °C Operating Humidity: 95% or Less (Non-condensing) Storage Humidity: 95% or Less (Non-condensing)
Special functions Smart Event: Intrusion Detection Line-Crossing Detection Region Entering Detection Region Exiting Detection Object Abandoned Detection Object Removal Detection Loitering Detection People Detection Vehicle Detection Abnormal Sound Detection Scene Change De

Extended warranties and insurance:

  • Additional warranty + insurance (2 + 1 year) - 99,99 €
  • Additional warranty (2 years) - 69,99 €
  • Insurance (1 year) - 89,99 €
  • Insurance (2 years) - 159,99 €

Choose a suitable extended warranty and insurance in checkout..

Dimensions and weights

Gross weight
1.05 kg
Package width
16 cm
Package height
16 cm
Package length
16 cm

Product codes

EAN
8885020627886
Manufacturer code
MOTPLKAMP000041
