Home page » Electronics»Smart home»Relays»TUYA Smart Circuit Breaker, 1P+N, Wi-Fi, RS485, 63A

TUYA Smart Circuit Breaker, 1P+N, Wi-Fi, RS485, 63A

Addional discount of 2%
will be applied in shopping cart
(min. 10€ purchase)
62,99 €

Monthly payment starting from 1,88 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

TUYA Smart 2-Pole (1P+N) switch for electrical devices, supporting remote control via 2.4GHz Wi-Fi with the TuyaSmart or SmartLife app; includes RS485 interface; DIN rail mountable; designed for various household appliances. Comes with 2 Wi-Fi antenn
Add to cart

Delivery in 4-7 working days

Delivery starting at 0 €

14 14 days return policy when purchasing online

TUYA Smart 2-Pole (1P+N) switch for electrical devices, supporting remote control via 2.4GHz Wi-Fi with the TuyaSmart or SmartLife app; includes RS485 interface; DIN rail mountable; designed for various household appliances. Comes with 2 Wi-Fi antennas. Equipped with energy metering functionality.
Features:The smart Wi-Fi circuit breaker with a maximum current of 63A is suitable for both residential and industrial use. This device not only provides protection against overload and short circuit but also enables remote control of electrical circuits and real-time monitoring of energy consumption.The smart breaker is easy to mount on a DIN rail and can be controlled remotely using the TuyaSmart or SmartLife mobile app (Android, iOS).Voice control is supported via Google Assistant and Amazon Alexa.The built-in energy metering function allows users to monitor and control power usage.Through the app, users can view real-time voltage, power, temperature, and energy data; set consumption thresholds; and configure automatic device shutdown.Energy consumption reports for household devices can be downloaded for accounting purposes.Remote control allows you to switch circuits on or off from anywhere.Custom scenes and automations are supported – devices or groups of devices can be programmed to turn on/off under specific conditions (e.g., a “leaving home” scene: turn off lights, water heater, TV, air conditioner, etc.).Automatic control: timers, schedules, cyclic on/off patterns, and delay settings can be configured as needed.Protection features include overload, short circuit, overvoltage, residual current (leakage), high temperature, and other electrical faults.A mechanical safety lock prevents the device from being switched on or accessed during maintenance or potentially hazardous procedures.Easy installation and operation.Includes RS485 communication interface.Equipped with a Wi-Fi signal LED indicator, a network detection button, mechanical locking, and a manual ON/OFF lever.This switch is compatible with a variety of other smart home products for creating advanced automation scenarios.
Technical specifications:Number of poles: 1P+N.Rated voltage: AC 230 V.Current: max. 63A.Frequency: 50/60 Hz.Breaking capacity: up to 6kA.Wi-Fi frequency: 2.4 GHz.Wi-Fi standards: 802.11b/g/n.RS485 interface: Yes.Control methods: Manual / Automatic.Protections: Overload / High temperature / Short Circuit / Overvoltage / Leakage.App: Tuya Smart / Smart Life (Android, iOS).Works with Amazon Alexa & Google Assistant.Operating temperature: -25°C to +70°C (max.).Mechanical lifespan: >10000 times.Electrical lifespan: >6000 times.Housing material: PC V0 (flame-retardant).Installation: DIN rail, 35mm.Certifications: CE, RoHS, IEC60898-1.Dimensions: 54x74x100 mm.Weight: 287g.Color: white.Set includes: 2x Wi-Fi antennas and RS485 adapter.
Warranty: 24 months.

Product codes

EAN
9990001084059
