FOLDING BRACKET WALL-MOUNT 19" 4U 497X400/240 GREY LANBERG

Ostukorvis rakendub
5% (lisa)allahindlust (min. 6€ ostul)
23,99 €

Põhiinfo

Lisa ostukorvi

Tarneaeg 7-10 tööpäeva

Kohaletoimetamine al. 0 €

14 14 päeva tagastusõigus internetist ostmisel

Vabandage, tooteandmed on tõlkimisel. Kui vajate toote võõrkeelse teksti mõistmisel abi, andke sellest palun teada e-posti teel info@photopoint.ee. Saadame teile kiirelt soovitud tõlke.


19" rack wall mounts – when to
use them instead of a rack cabinet?

A 19“ rack wall mount is an open, fold-out frame mounted directly to the wall, which allows you to install 19” standard devices without using a full-size RACK cabinet. The mount is also lighter and smaller than a classic enclosure, taking up less space. With this wall mount, you can install patch panels, switches, routers, CCTV recorders, or PDU strips exactly where you need them—e.g., above the administrator's desk, in a small technical room, at an access point, or in a cable shaft.

Compared to a standard standing or hanging cabinet, the 19" wall-mounted rack bracket takes up significantly less space, does not take up floor space, and its open design ensures natural cooling of the equipment. It is a good solution where:

  • the number of devices to be mounted is small (a few 1U/2U units),
  • simple and quick installation directly on the wall is important,
  • access to the devices does not need to be secured with a full server enclosure,
  • the budget is limited, and a full RACK cabinet would simply be overkill.

As a result, the wall mount for 19" rack devices is ideal for small server rooms, SOHO offices, service points, telecommunications cabinets, IP monitoring installations, VoIP, and access control systems.

Lanberg 19” wall mount rack – key features

The presented Lanberg 19“ rack wall mount is a 4U model, designed in the 19” standard, intended for direct wall mounting. It is a foldable hanging frame, designed for compact network and server installations.

Key technical data:

  • Standard: RACK 19“ (wall mount for 19” rack-compatible devices)
  • IT height: 4U
  • Mounting/working depth: adjustable from 240 to 400 mm, allowing the bracket to be adapted to different device models (from shallow patch panels to deeper switches).
  • Width: 497 mm
  • Depth: 400 mm
  • Maximum load: up to 12 kg, which in practice is sufficient for several 19" devices with cabling.
  • Material: steel hanging frame, designed to work with 19" standard devices (high rigidity and resistance to deformation).
  • Bracket weight: approx. 3 kg – facilitates wall mounting by one person.
  • Assembly: self-assembly, delivered in flat pack form (bracket for self-assembly, takes up little space in transport and storage).

The 19" standard front profiles allow for the installation of typical RACK devices: patch panels, cable management panels, small switches, NVR recorders, and PDU power strips. Standard M6 screw sets with baskets and washers are used to mount the equipment – exactly the same ones you use in RACK cabinets.

In addition, Lanberg offers compatible 19" RACK cabinets and brackets in several mounting heights (including 4U, 6U, and 8U) and in two colors – black and gray – allowing you to maintain consistency across your entire infrastructure in cabinets and brackets.

Quick installation, flexible cabling routing
and system expansion

The Lanberg 19“ rack wall mount has been designed as a practical alternative to hanging 19” rack cabinets in places where equipment accessibility and space saving are important. The fold-out frame design facilitates the installation of devices – first, you conveniently screw them to the 19" profiles, and then hang the whole unit on the wall. This solution allows for quick and easy installation, even by one person.

There are numerous mounting holes in the rear and sides of the bracket, which allow the frame to be hung using wall plugs selected for the type of wall and provide complete freedom in routing cables and wires to the installed devices. The open design at the top and bottom makes it easy to route cable bundles to cable trays, conduits, or cable ties without having to drill additional holes.

If you require greater protection against mechanical damage or want to partially “close” the installation, dedicated covers are available for the mount – top and bottom – which allow you to enclose the frame from above and below, creating something between an open mount and a light wall cabinet.

Thanks to this, the Lanberg 19" wall-mounted rack fits well into scenarios where:

  • access to devices is needed “at hand,” without opening the cabinet door,
  • there is no requirement to lock the installation,
  • it is crucial to quickly start up the station (e.g., a point network node, CCTV backbone, small distribution node in a building),
  • the possibility of subsequent expansion is important – if necessary, you can add another mount or plug the same set of devices into a larger RACK cabinet.

In summary: the Lanberg 19“ rack wall mount is a simple but very practical solution for installers who need a sturdy 19” frame mounted directly on the wall, with convenient access to equipment and cabling – without the cost and size of a full RACK cabinet.

Specyfikacja
Type of cabinet Wall mount
Assembly type Self-assembly
Working depth 400 mm
Colour Gray
RAL color RAL7035
ICT height 4 U
Depth 400 mm
Width 497 mm
Height 213 mm
Weight 3 kg

Mõõtmed ja kaalud

Brutokaal
3 kg
Pakendi laius
49.7 cm
Pakendi kõrgus
21.3 cm

Toote koodid

EAN
5901969447682
Tootja kood
FB01-5404-10S
